10~20 Ton/day Flake Ice Evaporator/Drum

MOQ:1 set
Payment: T/T, L/C
Lead Time:30 days after getting down payment
Certification:CE,ISO
Place of Origin:Shenzhen, China (Mainland)
Shipping Port:Shenzhen, China (Mainland)
Warranty:1 year
After-sales Service Provided:Engineers available to service overseas

Email: zx@iceevaporator.com

Tel: +86 13823344727

Whatsapp: +86 13823344727

10~20 Ton/day Flake Ice Evaporator/Drum

description1

Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Main Features

● Daily Capacity: 10~20 ton/day
● Ice Thickness:1.5-2.2MM
● Machine power supply:380V/50HZ,440V/60HZ,220V/60HZ/3P
● Cooling type:Freon or Ammonia
● The material of the ice evaporator could be carbon steel, SUS304, SUS316, it could be customized according to customers' requirements
● The outer cover, ice scraper, water distributor, water tank were built with SUS304, clean, sanitary, fully meet with foods grade
● Adopts top material, unique design, precision processing,high quality

Flake Ice Evaporator Application

Using for fishing ports and docks,refresh for aquatic products, cooling, fishery, concrete cooling food preservation, special areas of cooling,

Product Parameter
Flake Ice Evaporator Parameters

Model	Daily Output (T/24h)	Cooling method	Evaporative temp.	Cooling Capacity（Kcal/h)	Reducer Power(KW)	Unit Size (LWH mm)	Unit N.W. (KG)
ZFE-1T	1	Freon/Ammonia	-20C	5375	0.18	800530700	150
ZFE-3T	3	Freon/Ammonia	-20C	14250	0.37	115014001400	300
ZFE-5T	5	Freon/Ammonia	-20C	23750	0.37	150014001570	500
ZFE-8T	8	Freon/Ammonia	-20C	38000	0.37	185015002040	850
ZFE-10T	10	Freon/Ammonia	-20C	47500	0.75	200014001960	1050
ZFE-15T	15	Freon/Ammonia	-20C	71250	0.75	236017502150	1100
ZFE-20T	20	Freon/Ammonia	-20C	95000	0.75	236018002500	1200
ZFE-25T	25	Freon/Ammonia	-20C	11875	0.75	263020902500	1500
ZFE-30T	30	Freon/Ammonia	-20C	14250	1.5	280020902500	1850
ZFE-35T	35	Freon/Ammonia	-20C	19000	2.2	300021502500	2020
ZFE-40T	40	Freon/Ammonia	-20C	22360	2.8	300022802500	2500
ZFE-50T	50	Freon/Ammonia	-20C	28350	3.5	310023502650	2900
